Poly Pipe For electrical wiring installations are the best choice for domestic, industrial as well as commercial usage. Made from fresh high grade imported raw material. Pipes being rigid has a unique combination of strength, stiffness, flexibility without being brittle. Strong , highly durable our pipes provides better insulation and are impact resistant. Non corrosive in nature our pipes last long.
Features/ Advantages
- Non corrosive
- Light weight
- High tensile strength
- Spark retardant*
- UV stabilized
- High durability
- Impact resistant
- Maintenance free
- Long life
- One Side Socketed
- Smooth Finishing for Easy Pulling of Wires
- Easy to install (saves time and labour cost)
- Permanent and Clean Marking on Pipes.
- Made from high grade material.
Several Tests Like:
- Compression Test
- Bending Test
- Impact Test
- Collapse Test
- Resistance to Heat
- Electrical Characteristics test
Are Conducted Regularly by The Expert Technician Who Takes Random Samples from Different Lots to Check The Quality of The Pipes.
Applications:
- Channelising Concealed
- Out Door Electrical Installations
- Surface Wiring
- CCTV Fittings
- AC Pipes Ducting
- Cable Ducting
- Telecommunication
- Solar Panel Wire Fitting
- Wide Range Increases The Scope of Applications & Uses.
- We Have 3 Different Types of Ranges for Electrical Conduits
- Premium Range
- Medium Range
- Economy Range
SIZES, VARIANTS, RANGE OF CONDUITS
Premium Range
*SPECIAL SERIES
| SIZE(MM) |
NOMINAL SIZE(INCH) |
PRODUCT CODE |
STD PKG (PCS) |
COLOUR MARKING |
| 20 |
¾" |
20SPL |
50 |
GREEN |
| 25 |
1" |
25SPL |
25 |
GREEN |
| 32 |
1 ¼" |
32SPL |
25 |
GREEN |
| 40 |
1 ½" |
40SPL |
25 |
GREEN |
*STANDARD SERIES
| SIZE(MM) |
NOMINAL SIZE(INCH) |
PRODUCT CODE |
STD PKG (PCS) |
COLOUR MARKING |
| 20 |
¾" |
20ST |
50 |
BLUE |
| 25 |
1" |
25ST |
25 |
BLUE |
| 32 |
1 ¼" |
32ST |
25 |
BLUE |
| 40 |
1 ½" |
40ST |
25 |
BLUE |
| 50 |
2" |
50ST |
18 |
BLUE |
| 63 |
2½" |
63M |
12 |
BLUE |
*HEAVY SERIES
| SIZE(MM) |
NOMINAL SIZE(INCH) |
PRODUCT CODE |
STD PKG (PCS) |
COLOUR MARKING |
| 20 |
¾" |
20HD |
50 |
GREEN |
| 25 |
1" |
25HD |
25 |
GREEN |
| 63 |
2 ½" |
63H |
12 |
GREEN |
*SUPER SERIES
| SIZE(MM) |
NOMINAL SIZE(INCH) |
PRODUCT CODE |
STD PKG (PCS) |
COLOUR MARKING |
| 20 |
¾" |
20S |
50 |
BLUE |
| 25 |
1" |
25S |
25 |
BLUE |
| 32 |
1 ¼" |
32S |
25 |
BLUE |
| 40 |
1 ½" |
40S |
25 |
BLUE |
| 50 |
2" |
50S |
18 |
BLUE |
Medium Range
| SIZE(MM) |
MEDIUM |
LIGHT |
STD PKG(PCS) |
| 20 |
M |
---- |
50 |
| 25 |
M |
1MM |
40 |
| 32 |
M |
---- |
25 |
| 40 |
M |
---- |
25 |
| 63 |
M |
---- |
12 |
Economy Range
| SIZE(MM) |
VARIANT / mm |
STD PKG(PCS) |
| 20 |
1 |
50 |
| 25 |
1.2 |
40 |
| 25 |
1.4 |
40 |
| 25 |
2 |
40 |
*Colours : White / Ivory , Grey
*PVC is inherently self extinguishing as it does not support combustion.Pvc has high limiting oxygen index (loi) of 45.Loi is the percentage of oxygen needed in an atmosphere to support combustion. Since the earth’s atmosphere is only 21% oxygen, it is ideally suited for use in buildings and houses
